產品規格

SCREEN SIZE (INCH)
23.8
FLAT / CURVED
Flat
PANEL TREATMENT
Antiglare (AG)
PIXEL PITCH (MM)
0.2745
PIXELS PER INCH
93
PANEL RESOLUTION
1920x1080
ASPECT RATIO
16:9
BACKLIGHT TYPE
WLED
MAX REFRESH RATE
100 Hz
RESPONSE TIME GTG
14 ms
RESPONSE TIME MPRT
1 ms
VIEWING ANGLE (CR10)
178/178
DISPLAY COLOURS
16.7M (6bits+FRC)
BRIGHTNESS IN NITS
250 cd/m2
OD RESPONSE (TYPICAL)
4 ms GtG
PANEL HAZE VALUE
25%
LOCAL DIMMING ZONES
Global Dimming
Video Features
SYNC TECHNOLOGY (VRR)
Adaptive Sync
DIGITAL SIGNAL FREQUENCY VERTICAL
48-100Hz
DIGITAL SIGNAL FREQUENCY HORIZONTAL
30k-115Khz
HDR (HIGH DYNAMIC RANGE)
HDR Mode
COLOUR SPACE (SRGB) CIE 1931 %
100.1
COLOUR SPACE (SRGB) CIE 1976 %
95.2
COLOUR SPACE (DCI-P3) CIE 1931 %
73.8
COLOUR SPACE (DCI-P3) CIE 1976 %
73.8
COLOUR SPACE (ADOBE RGB) CIE 1931 %
74.2
COLOUR SPACE (ADOBE RGB) CIE 1976 %
81.6
COLOUR SPACE (NTSC) CIE 1931 %
70.9
COLOUR SPACE (NTSC) CIE 1976 %
83
COLOUR SPACE (BT 709) CIE 1931 %
100.1
COLOUR SPACE (BT 709) CIE 1976 %
95.2
COLOUR SPACE (BT 2020) CIE 1931 %
53
COLOUR SPACE (BT 2020) CIE 1976 %
55.2
FLICKER-FREE
Flicker Free
Cabinet information
BEZEL TYPE (FRONT)
Ultra Narrow
BEZEL COLOUR (FRONT)
Black
BEZEL FINISHING (FRONT)
Texture
SPEAKERS
✓
SPEAKER POWER
2 W x 2
KENSINGTON LOCK
✓
VESA WALLMOUNT
100x100
I/O DEFINE: CONNECTORS ON REAR CABINET
Vertical insert
QUICK RELEASE FUNCTION
✓
VESA MOUNT SCREW SPEC
M4 x 10
Ergonomic information
TILT
Retrieving data. Wait a few seconds and try to cut or copy again.
Sustainability
CARTON MATERIAL
Paper
CARTON MATERIAL PRINT
Water Print (Brown Carton)
Power Consumption
POWER SUPPLY
Internal
POWER SOURCE
100 - 240V 50/60Hz
POWER CONSUMPTION ON (MAXIMUM) IN WATTS
32
POWER CONSUMPTION ON (TYPICAL) IN WATTS
20
POWER CONSUMPTION STANDBY IN WATTS
0.5
POWER CONSUMPTION OFF IN WATTS
0.3
POWER LED INDICATOR (OPERATION)
White/Blue
POWER LED INDICATOR (STANDBY)
Orange
Connectivity information
HDMI
HDMI 1.4 x 1
DIGITAL HDCP (HDMI VERSION)
HDCP 1.4
AUDIO OUTPUT
1x Audio out
D-SUB (VGA)
1x
DVI
0x
RJ45
No
Product Dimensions
PRODUCT DIMENSIONS INCL. BASE (WXHXD) MM
542.4 x 412.1 x 202.3
PRODUCT DIMENSIONS EXCL. BASE (WXHXD) MM
542.4 x 316.2 x 44.6
PACKAGING DIMENSIONS (WXHXD) MM
614 x 126 x 394
PACKAGING DIMENSIONS (WXHXD) MM (CN)
614 x 126 x 394
GROSS WEIGHT INCL. PACKAGE (IN KG)
4.65
NET WEIGHT EXCL. PACKAGE (IN KG)
2.97
GROSS WEIGHT INCL. PACKAGE (IN KG) (CN)
4.65
PRODUCT WITHOUT STAND (KG)
2.65
Other information
OPERATION SYSTEM
Windows 8.1/10/11, MacOS
PLUG & PLAY COMPATIBILITY
Yes, DDC/CI
Maximum Resolution by connector
DEFAULT RESOLUTION BY INPUT
1920 x 1080
MAX RESOLUTION BY INPUT
1920 x 1080
